Product Overview
Brand: EffEff
Features:
- Fits standard doors
- Packaging: 1 - Manufacturer's reference: 118.13------A71 - Series: 118 - Maximum voltage (V): 24 - Minimum voltage (V): 10 - Type: single current emissions
Details: For standard door - symmetrical strike body Until then, the profile had to be notched to swivel the strike. ProFix combines a FaFix strike with a half-turn bolt guide built into the strike. Adaptable to all commonly used effeff headrests. Reversible DIN left or DIN right by 180° rotation. Fafix adjustment: 3 mm. Half turn socket depth: 5.5 mm. Nominal resistance: 118: 43 Ω, 138: 51 Ω. Current consumption: 118: 250 mA. 11118 : 235 mA. Burglar resistance: 3750 N. Operating temperature range: -15 °C to +40 °C. Installation position: vertical and horizontal. Case material: zinc. Material of half-turn: steel. Delivered without headrest. Packaging: 1. Manufacturer's reference: 118.13 ------A71 - Series: 118 - Maximum voltage (V): 24 Voltage Mini (V): 10 - Type: Simple current emission
EAN: 4042203354135
