Product Overview
Brand: PATIKIL
Features:
- CBB61 capacitor is a metalized polypropylene film capacitor, which is mostly used in AC motors, used as a starting capacitor for fans and air conditioners to maintain motor operation, and also can use for range hood fans, air exchange fans, pumps, motors, generator, etc.
- Model: CBB61; Material: Polypropylene Film Plastic Shell; Terminal: 4 wires; Tolerance: ±5%; Rated Capacity: 5+5uF; Climatic Category: 40/85/21; Body Size:47 x 22 x 35mm/1.83 x 1.01 x 1.37inch(L x W x H); Wire Length:12cm/0.47inch; Shell Color: Black; Rated Voltage: 250V AC; Rated Frequency:50/60Hz;Switch Rated current /voltage: 3A 250V/6A 125V;Switch size：31 x 19mm/1.2 x 0.74inch(W x H); Switch Wire Length: 10cm/3.9inch;Pack of 1set ( 1pcs CBB61 Capacitor + 1pcs switch)
- Advantage: This CBB61 run capacitor has characteristics of small volume, lightweight, low loss, strong overload ability, excellent electrical performance, reliable insulation performance, and current with good impact resistance.
- Instruction: Capacitance is not divided into positive and negative state and can be connected at will. High stability, good heat dissipation effect under high temperature.
- NOTE: Please pay attention not to over current or over voltage when using
Details: CBB61 capacitor is a metalized polypropylene film capacitor, which is mostly used in AC motors, used as a starting capacitor for fans and air conditioners to maintain motor operation, and also can use for range hood fans, air exchange fans, pumps, motors, generator, etc. Specification: Model: CBB61; Material: Polypropylene Film Plastic Shell; Terminal: 4 wires; Tolerance: ±5%; Rated Capacity: 5+5uF; Climatic Category: 40/85/21; Body Size:47 x 22 x 35mm/1.83 x 1.01 x 1.37inch(L x W x H); Wire Length:12cm/0.47inch; Shell Color: Black; Rated Voltage: 250V AC; Rated Frequency:50/60Hz;Switch Rated current /voltage: 3A 250V/6A 125V;Switch size：31 x 19mm/1.2 x 0.74inch(W x H); Switch Wire Length: 10cm/3.9inch;Pack of 1set ( 1pcs CBB61 Capacitor + 1pcs switch) Advantage: This CBB61 run capacitor has characteristics of small volume, lightweight, low loss, strong overload ability, excellent electrical performance, reliable insulation performance, and current with good impact resistance. Instruction: Capacitance is not divided into positive and negative state and can be connected at will. High stability, good heat dissipation effect under high temperature. NOTE: Please pay attention not to over current or over voltage when using
