Product Overview
Brand: MacMaxe
Color: Brown,red
Features:
- ULKA Model E, Type EX5 120V, 60Hz 41W and Two O-Ring for Hydraulic Seal of Pump Outlet
- Self priming at 0 bar, Integrated diode (1N 4007P), Thermal cutout pocket, Pressure max 15 bar.
- Compact solution for high pressure and low flow applications.
- Full detailed electrical and hydraulic inspection
- Replacement for Rancilio part : 34011023
Details: Model E, Type EX5 120V, 60Hz 41W. fittings ø 1/8"- ø 6 mm; pressure max 15 bar; water temperature max 25°C; integrated diode (1N 4007P); lead connector 6.3x0.8 mm; All pumps are designed and tested using water as fluid. Pump should have water inside after removing red cap off of water inlet. A brown stain may be visible around the water inlet, it is normal. We do not recommend to stock the pumps for long time, especially in high temperature storage house and in particular for pumps without water inside. Sometimes pumps will develop an airpocket in shipping or from storage. TO WORK PROPERLY, PUMP MUST HAVE WATER INSIDE . EMPTY PUMP WILL MAKE A LOUD BUZZING NOISE. To remove the airpocket, use a syringe filled with water and push the water through the pump. Make sure the other end is clear and drained, or connected within machine and air can escape the other side. The thread connection G 1/8“ of the plastic pump outlet is not subject to the norm UNI ISO 228/2. The seal is not guaranteed by the thread. In fact the hydraulic seal has to be assured by the seal OR 2025 Ø 1.76 x 6.07 mm. (Seal include in the package) Replacement Pump for Espresso Machine with Part# ASCASO V..658, BEZZERA 7731011, 7731019 BRASILIA 17572.4.00.08 CASADIO 533194820 CIMBALI 533-194-820 ELEKTRA 255035 EXPOBAR 60000047 FAEMA 533194820 FIORENZATO C.S. A1900044 GAGIA 187720955 GRIMAC MG072, 1220300006 LA PICCOLA C07-EFX5/110 NUOVA RICAMBI 617160/11 NUOVA SIMONELLI 4800006 QUICK MILL PO08700V1 RDL 14200030 RICAMBI GARDOSI V082 SAECCO 187720955, 9070.026.00F SCALA C-0584 SPAZIALE 07639 SPINEL SR.000.054.004 VIBIEMME POMPVIBDOM100, POMPVIBDOM120 VICTORIA ARDUINO 04800006 WEGA
